Field-portable gas analysis, Foresight-ready
The SA-PMSA is a field-portable, aspirated analyzer built for multiple applications. Equipped with four dual-sensor stainless steel chambers that hold up to eight sensors. The device also has integrated sample filtration - water separator, coalescing filter, and pump - protects the sensors in harsh conditions. Onboard data logging, with optional data push to Foresight, where the Digital Layer turns raw channel data into ranked, explainable diagnostics.
Eight sensor channels, integrated sample filtration, and a battery - in a case you can carry.
Four dual-sensor chambers
Four stainless steel chambers hold up to eight smart sensors. Water separator and coalescing filter condition the sample before it reaches the cells, so harsh field conditions don't shorten sensor life.
Sixteen target gases, eight at a time
Configure any eight sensors across the catalog below. Modules are field-replaceable, so a single case can be re-tasked between applications as monitoring requirements change.
The digital layer that turns channel readings into a diagnosis.
Diagnose
Establish how the unit runs when it is healthy, so every later reading is judged against that machine rather than a generic table.
Test
Each channel is measured and time-stamped, then pushed to Foresight wirelessly and trended over time against your operating limits.
Recommend
Foresight ranks the probable causes with confidence scores, shows the supporting evidence, and builds the records your reporting requires.
Where this product is deployed
- Landfill reclamation gas analysis
- Combustion applications - initial diagnosis and testing
- Portable construction monitoring
- Disaster response site monitoring
Features & Capabilities
Sensing & Sample Handling
- Four dual-sensor stainless steel chambers - 8-sensor capacity
- Aspirated sample draw with integrated pump
- Water separator and coalescing filter
- Field-replaceable smart sensor modules
Interface & Data
- Color LCD HMI with live channel-by-channel readings
- Onboard data logging with download via onboard Wi-Fi
- Wireless capable for access to test execution and onboard recommendations.
- Optional access to synchronize with Combustion Fleet Management to update the device knowledge base.
Portability & Build
- NEMA 4X weatherproof transport case
- 12 V rechargeable battery for untethered field testing
- 20.66 in (W) × 17.2 in (D) × 8.4 in (H)
- Ruggedized for truck-to-site handling
Foresight-Ready Analytics
- Baseline capture per unit
- Ranked observations to help identify root cause - with confidence scores
Technical Specifications
SA-PMSA Documentation
Product data sheet and full product manual for the SA-PMSA Portable Multi-Sensor Analyzer - available to view inline or download.
Full specifications, features, and applications in a printable PDF.
SA-PMSA Product Manual (Rev 00)
SA-PMSA ManualInstallation and service manual for the SA-PMSA Portable Multi-Sensor Analyzer - operation, calibration, maintenance, and service procedures.
