SA-XES Manual · Rev 2
SA-XES Aspirated Multi-Sensor System - Installation & Service Manual
Installation, wiring, configuration, and service procedures for the SA-XES aspirated multi-sensor system - available to view inline or download.
About this manual
The SA-XES installation and service manual covers aspirated multi-sensor systems: sample line routing and length limits, pump and flow configuration, filter and moisture management, multi-gas sensor setup, calibration through the sample path, and scheduled service of flow components.
Written for engineers and technicians designing, commissioning, or servicing aspirated sample-draw gas detection systems.
What's inside
- Safety information and system overview
- Sample line design, length, and material
- Mounting the SA-XES enclosure
- Pump, flow, and filtration setup
- Multi-sensor configuration and gas assignment
- Flow fault detection and alarms
- Calibration through the sample path
- Filter replacement and scheduled service
- Troubleshooting flow and sensor faults
Frequently asked questions
How long can an SA-XES sample line be?
- Maximum sample line length depends on tubing diameter, pump setting, and target response time. The manual gives the design limits and response-time guidance.
How is an aspirated system calibrated?
- Calibration gas is applied through the sample path so the measured response includes transport delay. The manual documents the procedure step by step.
What maintenance does the SA-XES require?
- Routine service covers filter replacement, flow verification, pump inspection, and sensor calibration on the schedule documented in the manual.
